Preparation of Sodium Tungstate from Waste Catalyst Containing Tungsten and Nickel
Sodium tungstate was prepared by roasting plus sodium-leaching-ion exchange and with waste tungsten-nickel hydrogenation catalyst as the raw material.
The results show that the tungstate leaching rate from waste catalyst can reach 99% when the catalyst grinding size is 0.15 mm,the ratio of Na2CO3 dosage to WO3 dosage 0.69,leaching temperature 90 ℃,and leaching time 1 h. The saturation ion-exchange capacity of WO3 is 332.9 gWO3/L-dry resin with the method of serial column absorption. The WO3 desorption rate is 98.2% with 2 mol/L NaCl and 1 mol/L NaOH mixture solution as the desorption agent. The purity of sodium tungstate is 99% after recrystallization.
Related Products:
0.6um yellow tungsten oxide is a kind of tungsten oxide, with a positive yellow powder appearance, stable properties at normal temperature and apparent density of 0.6-1.0g/cm3.
Ammonium metatungstate(AMT) is an important intermediate compounds of tungsten hydrometallurgical process, appearance is white crystalline powder, solubility in water is the largest in the tungsten compounds which over 300g WO3/100ml H2O (in 25℃).
Sodium tungstate, a tungstate of sodium, is useful as a source of tungsten. It is prepared from tungsten ores used to manufacture tungsten by reducing it.
Purple Tungsten oxide is divided into WO2.72 (or W18O49). It is a kind of tungsten oxide. It is abbreviated as VTO. It is a purple finely grained crystalline powder, and its color usually appears purple or blue purple.
